Hip Ridge and Pyramid Dome Skylights

VELUX Hip Ridge and Pyramid dome commercial skylights

  • Standard sizes available now,  custom sizes coming soon
  •  Will be available in any size ¼" increments
  • No minimum order quantity
  • Works with all VELUX commercial skylight curb and fall protection accessories

Hip Ridge Dome

Prismatic maximum size:
Acrylic = 70" x 120" Polycarbonate = 60" x 120"

Pyramid Dome

Prismatic maximum Size:
Acrylic = 70" x 70" Polycarbonate = 60" x 60"

New and improved frame design

red 1  50-year Silicone
red 2  Glazing Spacer
  • Reduced cracking
  • Condensation release
red 3  Inner dome rests on material with similar expansion/contraction (durability)
red 4  Innovative, encapsulating one-piece Thermoplastic inner frame.
  • Dry installation (no caulk or curb tape needed)
  • Impenetrable water barrier
  • No exposed holes to the exterior (air/water/bug filtration)
  • 100 percent thermally broken (the frame is the thermal break)
  • Fail-safe extra layer of water protection; no path for water to enter the building.

The benefits of Hip Ridge & Pyramid Dome Skylights

Superior Water Management

Unlike most commercial skylights that allow condensation to collect within an interior gutter, VELUX Domes utilizes a fail-safe proprietary wicking system that evacuates condensation to the exterior of the skylight. We’ve also incorporated a one-piece inner frame, creating superior durability (eliminating the need for corner welds that can leak) and 50-year silicone.

Secure Thermal Seal

VELUX  Dome incorporates an encapsulating design that provides an impenetrable water barrier with a 100 percent thermally broken skylight frame, thereby isolating interior surfaces from exterior temperatures. This 'warm design' virtually eliminates condensation while also providing a secure weather seal to the curb to impede air, water, and bug infiltration..

Glazing options

Standard options Outer dome material Inner dome material Glazing code
LuxGuard
Certified 		UV guard coextruded polycarbonate smooth clear Polycarbonate prismatic white 3P1C2
LuxGuard plus
Certified, HVHZ, Impact 		UV guard coextruded polycarbonate smooth clear Polycarbonate prismatic white 2P1C2
15-year WARRANTY on LuxGuard options, Including breakage (hail breakage up to 2” in diameter)
Impact modified acrylic
Certified 		100% Impact modified acrylic smooth 50% Impact modified acrylic prismatic white 121N2
Basic acrylic Smooth acrylic clear Smooth acrylic white 0AA1A2

Frame finish

Model Frame finish Number of domes
CH2 Mill Double dome
CH1 Mill Single dome
